60MHz Function Signal Generator High Precision Digital DDS Dual-channel Function Signal/Arbitrary Waveform Generator Pulse Signal Source 250MSa/s Frequency Meter VCO Burst AM/PM/FM/ASK/FSK/PSK Modulation DDS Generator Function Source Generator all functions can be controlled by PC program and communication protocol is open for secondary development. Enable to store 64 arbitrary waveform data files, each one of waveform storage depth 8192 points * 14bits; ( longer waveform storage depth, more detail waveform is saved, and signal details can be restored with high precision.) voltage controlling frequency, voltage controlling amplitude, voltage controlling offset, voltage controlling duty cycle and PWM modulations. Adopt ABS shell with table type design. Use 100-240V (AC) wide voltage supply. it can 4 properties of signals including frequency, amplitude, offset and duty cycle; It has Linear and Logarithm two types; 0.01S999.99S time; , Down and roundtrip directions. Adopt MagicPulse Technology, Low Jitter(RMS)&lt;200ps. Adopt Direct Digital Synthesizer (DDS) technology and provide stable, precise, pure and low distortion signals. Provide powerful waveform editing PC software. Users can download arbitrary waveform to this instrument after edit through PC program which is included in user . there has Manual Trigger, internal CH2 Trigger, and External Trigger for your options. It can output 11048575 pulse trains. Standard dual full functional channels which are equivalent to two independent generators. AM, , PM, ASK, FSK and PSK modulations. 2.4 inch TFT color LCD with 320*240 resolution, simultaneously display parameters and graphics of CH1 and CH2. support waveform copy and state copy between channels. it can save 20 sets user-set parameters and can be loaded at any time. Duty-cycle of each channel can be adjusted independently 0.01%-99.99%, adjusting resolution is 0.01%. -12V+12V Offset function. Resolution 0.001V. it has 2 coupling measure modes including coupling and AC coupling. This design can solve inaccuracy problem of AC coupling. Min amplitude resolution can be to 1mV. Amplitude is 1mV24Vpp. Sine, (Duty Cycle adjustable), Pulse (Pulse width and cycle time can be set accurately), Triangle/Ramp, CMOS(012V), Four channels TTL, Exponential Rise, Exponential Fall, Noise, etc. Precisely adjust phases of two channels. Precision can be 0.01°. all channels can work more than 60 seconds when load is short-circuited. Support two or more signal generators connected to achieve multi-channel output, maximum support 16-channel synchronous output, phase between each channel can be adjusted. instrument uses 14-bit high-speed D/A converter chip (5Vpp output quantization error is less than 1mV), 250MSa/s sample rate, 14bits vertical resolution.<br><br>Specification:<br>Display: 2.4 inch (320*240), TFT color display<br>Modulation Type: AM, , PM, ASK, FSK, PSK<br>Plug &amp; Model: Plug FY6900-20M / Plug FY6900-60M / Plug FY6900-100M / Plug FY6900-20M / Plug FY6900-60M / Plug FY6900-100M / AU Plug FY6900-60M (Optional)<br>: AC100V~240V<br>Waveform Length: 8192 points * 14bits<br>Item Size: 210 * 195 * 75mm / 8.27 * 7.68 * 2.96in (L*W*H)<br>Package Weight: 1065g / 37.51oz<br>Item Weight: 611g / 21.56oz<br>Sampling Rate: 250MSa/s(20M,60M), 300MSa/s(100M)<br>Package Size: 27 * 21 * 9.5cm / 10.63 * 8.27 * 3.75in<br>Vertical Resolution: 14 bits<br>Sine: 0~20MHz(20M), 0~60MHz(60M), 0~100MHz(100M)<br>Output Amplitude : 1mV24Vpp(20M,60M), 1mV25Vpp(100M)<br>Non-Volatile Storage: Can store 64 user-defined arbitrary waveforms, (8K 14bits) * 64<br>Minimum Pulse Width: 20ns<br>Material: ABS<br><br><br>Package List:<br>1 * Cable<br>1 * USB Data Cable<br>1 * DDS Signal Generator<br>2 * BNC-Clip Cable<br>1 * BNC-BNC Cable<br>

• Counter Function: it has 2 coupling measure modes including DC coupling and AC coupling. This design can solve inaccuracy problem of AC coupling.
• Burst Output Function: there has Manual Trigger, internal CH2 Trigger, and External Trigger for your options. It can output 11048575 pulse trains.
• VCO Function (Voltage Control Output): can be achieved by an external input signal: voltage controlling frequency, voltage controlling amplitude, voltage controlling offset, voltage controlling duty cycle and PWM modulations.
• Adopt MagicPulse Technology, Low Jitter(RMS)<200ps.
• Adopt the Direct Digital Synthesizer (DDS) technology and provide stable, precise, pure and low distortion signals.
